Thermally Conductive Adhesive Tape & Thermal Interface Tape

Thermal Tape is made of an advanced thermal conductive pressure-sensitive adhesive. This tape series includes thermal tape, thermal insulation tape, heat sink tape, thermal adhesive tape, thermally conductive tape, 3m thermal tape, thermal tape for heatsink, double sided thermal tape, thermal bond, thermal transfer tape, thermal tape for GPU, heat conductive tape, best thermal tape, 3m 8815, thermally conductive adhesive tape, thermal insulation tape high temperature, thermal heat tape, thermal tape for CPU, thermal conductive tape double-sided, heatsink adhesive tape suitable to apply to electronic mechanical components assembly such as the heatsink module and LED light bar module to provide a better heat-transfer path between heat-generating components and heat sink or other cooling devices.
First 1234 Last

What Is Thermally Conductive Adhesive Tape?

Thermally conductive adhesive tape — also called thermal interface tape — is a double-sided tape that bonds a heat-generating component to a heat sink or housing while conducting heat across the bond line. The adhesive is a pressure-sensitive acrylic filled with thermally conductive particles such as ceramic or boron nitride, so it replaces both a mechanical fastener and a separate thermal interface material (TIM) in one step.

Thermal Tape — Cross-SectionThermal Tape layer structure: Release liner (peel off) over Adhesive (side 1) over Thermally conductive core over Adhesive (side 2) bonding a surface. Thermal Tape — Cross-SectionRelease liner (peel off)Adhesive (side 1)Thermally conductive coreAdhesive (side 2)Bonded surface / substratepeelTotal thickness
Figure 1: Thermal Tape layer structure (indicative, not to scale).
Figure summary: Thermally conductive tape carries heat between a component and a heatsink: a thermally conductive core (often filled adhesive or a carrier) with adhesive on both faces bonds and fills the air gap, so heat conducts across the joint instead of being trapped by an insulating air layer.

Unlike thermal paste, a thermally conductive tape provides its own structural bond, so no clips or screws are required. This makes it a clean, fast assembly solution for electronics where space and weight matter.

Thermal Interface Tape Types & Indicative Specifications

Industrial thermal conductive tapes are offered in several constructions to balance bond strength, thickness and heat transfer. Values below are indicative industry ranges — contact us for the data sheet matched to your application.

PropertyIndicative Range
ConstructionFilled acrylic PSA, with or without fiberglass/PET carrier
Thermal conductivity~0.3 – 1.5 W/m·K (filled acrylic tape class)
Thickness0.10 – 0.50 mm typical
Operating temperatureapprox. −40 °C to +150 °C
FormatDouble-sided rolls, die-cut pads, custom shapes

Applications of Industrial Thermal Conductive Tapes

Thermally conductive tapes are used wherever heat must move from a component into a heat sink, frame or chassis while the parts are bonded together: LED lighting modules and strips, power electronics and IGBT/MOSFET packages, EV and energy-storage battery packs, PCB-to-heatsink mounting, CPU/GPU and memory cooling, and telecom and automotive control units.

Frequently Asked Questions

What is thermal interface tape?

Thermal interface tape is a double-sided adhesive tape that conducts heat from a hot component to a heat sink while bonding the two parts together. It combines the roles of a thermal interface material and a mechanical fastener in one tape.

How is thermally conductive tape different from thermal paste?

Thermal paste only transfers heat and needs a separate clip or screw to hold parts together. Thermally conductive adhesive tape both transfers heat and provides the structural bond, so no extra fasteners are required.

What thermal conductivity do these tapes provide?

Filled-acrylic thermal conductive tapes typically fall in the ~0.3–1.5 W/m·K range depending on filler and thickness. The right grade depends on heat load and bond-line thickness — contact us for a recommendation.

Where are thermally conductive adhesive tapes used?

Common uses include LED lighting, power electronics, EV battery packs, heat-sink mounting, PCB cooling and automotive electronics — any assembly that must bond parts and move heat at the same time.

Can the thermal interface tape be die-cut to shape?

Yes. These tapes are supplied as rolls and can be die-cut into pads or custom shapes to match your component footprint.
